Precision Balances FZ-i Series





Kitoma Indonesia  - Menyediakan Precision Balances FZ-i Series


Precision Balances with an Internal Calibration

High Functionality You Can Afford!


FZ-i Series

FZ-120i : 122 g x 0.001
FZ-200i : 220 g x 0.001
FZ-300i : 320 g x 0.001
FZ-500i : 520 g x 0.001
FZ-1200i : 1220 g x 0.01
FZ-2000i : 2200 g x 0.01
FZ-3000i : 3200 g x 0.01
FZ-5000i : 5200 g x 0.01






Features FZ-i Series

  • One touch automatic calibration
  • Compact, B5 size footprint
  • Fast, 1 second stabilization
  • Large bright Vacuum Fluorescent Display
  • Shock absorber function
  • Multiple weighing units
  • GLP/GMP/GCP/ISO compliant
  • Statistical calculation function
  • Response adjustment function
  • ACAI – Automatic Counting Accuracy Improvement
  • Built-in rechargeable battery (optional)



External Input / Output

  • RS-232C interface
  • Quick USB interface (optional)
  • LAN – Ethernet interface with WinCT-Plus software (optional)



Option

  • FXi-02 : Quick USB interface with cable
  • FXi-08 : Ethernet interface with WinCT-Plus software
  • FXi-09 : Built-in rechargeable battery
  • FXi-10 : Small breeze break
  • FXi-11 : Large breeze break
  • FXi-12 : Animal weighing pan (FZ-1200i / 2000i / 3000i)
  • FXi-15 : Carrying case

* FX-02, FXi-08 and FXi-09 cannot be used at the same time.



Accessories

  • AD-1683 : Static Eliminator
  • AD-1684 : Electrostatic Fieldmeter
  • AD-1689 : Tweezers for Calibration Weight
  • AD-8920A : Remote Display
  • AD-8922 : Remote Controller
  • AD-8121B : Compact printer
  • AD-8118C : Universal Printer
  • AD-8526 : Serial / Ethernet Converter
  • AX-USB-9P : Serial / USB Converter
  • AX-KO2466-200 : RS-232C Cable (9P-9P)
  • AX-CARATPAN-W : Carat pan (silver, 2pcs.)
  • AX-CARATPAN-B : Carat pan (black, 2pcs.)
  • AX-FXi-31 : Main Unit Cover (5pcs.)



Specifications FZ-i Series



  FZ-120i FZ-200i FZ-300i FZ-500i FZ-1200i FZ-2000i FZ-3000i FZ-5000i
Capacity x
Resolution
g 122 x 0.001 220 x 0.001

320 x 0.001

520 x 0.001 1220 x 0.01 2200 x 0.01 3200 x 0.01 5200 x 0.01
oz 4.30 x 0.00005 7.76 x 0.00005 11.28 x 0.00005  18.34 x 0.00005 43.0 x 0.0005 77.6 x 0.0005 112.8 x 0.0005

183.4 x 0.0005

lb 0.268 x 0.000005 0.485 x 0.000005 0.705 x 0.000005  1.14 x 0.000005  2.68 x 0.00005 4.85 x 0.00005 7.05 x 0.00005 11.46 x 0.0005
lb-oz 0lb, 4.30oz x 0.01oz 0lb, 7.76oz x 0.01oz 0lb, 11.29oz x 0.01oz  0lb, 18.34oz x
1lb, 0.01oz
2lb, 11.03oz x0.01oz 4lb, 13.60oz x0.01oz 7lb, 0.88oz x0.01oz

11lb, 7.65 x
1lb, 0.001oz

ozt 3.92 x 0.00005 7.07 x 0.00005 10.28 x 0.00005  16.71 x 0.00005 39.2 x 0.0005 70.7 x 0.0005 102.8 x 0.0005 167.18 x 0.005
ct 610 x 0.005 1100 x 0.005 1600 x 0.005  2600 x 0.005 6100 x 0.05 11000 x 0.05 16000 x 0.05 26000 x 0.05
dwt 78.6 x 0.001 141.7 x 0.001 206.2 x 0.001 335.1 x 0.001  786 x 0.01 1417 x 0.01 2062 x 0.01 3351 x 0.01
GN 1882 x 0.02 3395 x 0.02 4938 x 0.02 8024 x 0.02  18827 x 0.2 33951 x 0.2 49383 x 0.2 80248 x 0.2
Counting Mode Min. Unit
Mass
0.001g 0.01g
# of
Samples
5, 10, 25, 50 or 100 pieces
Percent Mode Min. 100%
Ref. Mass
0.100g 1.00g
Min. 100%
Display
0.01%, 0.1%, 1% (depends on the reference mass stored)
Repeatability
(Std. Deviation)
0.001g 0.01g
Linearity ±0.002g ±0.02g
Stabilization Time
(typically set at FAST)
Approx. 1 second
Sensitivity Drift
(10°C to 30°C)
±2ppm / °C
Operating Temp 5°C to 40°C (41°F to 104°F), 85% RH or less (No condensation)
Display Type Vacuum Fluorescent Display (VFD)
Display Refresh Rate 5 times / second, 10 times / second or 20 times / second
Std. Serial Interface RS-232C Interface
Weighing Pan 130mm 150mm
External Calibration 100g
50g
200g
100g
300g
200g
100g
 500g
400g
300g
200g
100g
50g
1000g
500g
2000g
1000g
3000g
2000g
1000g
 5000g
4000g
3000g
2000g
1000g
500g
AC Adaptor Confirm that the adaptor type is correct for the local voltage and power receptacle
Power Consumption Approx. 11VA (supplied to the AC Adaptor)
External Dimensions 193 (W) x 262.5 (D) x 84.5 (H) mm
Net Weight Approx. 2.5kg



Instructions Manual

Button-download.pngBrochure
